An 8' wide Sooner Ranch gooseneck stock trailer provides you with the extra room when you need it most. With over 8 feet of interior width, and with standard lengths up to 28 feet available, these models allow you to haul more livestock than ever, while still being able to enjoy the advantages of a premium Sooner trailer.
| Coupler Type: | Gooseneck |
| Trailer Width: | 8'0" outside width |
| Inside Height: | 6'8" or 7'2" inside height |
| Length: | 20' (8020), 24' (8024) or 28' (8028) |
| Exterior: | Sooner exclusive triple hollow core aluminum slat; .063 white aluminum sheets on 8' tapered nose |
| Air Spacing: | Two air gaps w/ Plexiglas tracks |
| Rear Gate: | Full swing rear door w/ matching air gaps and easy-glide slider w/ handle; Heavy-duty galvanized pipe hardware on rear gate; Rear gate slam latch on streetside rear post |
| Center Gate: | One center gate w/ slider (2 on 24'-28' models); Heavy-duty slam latch w/ external release |
| Drop Partition: | Gooseneck partition w/ spring loaded latches |
| Side Unload Door: | Heavy-duty 54" streetside access door w/ matching air gaps |
| Floor: | Heavy-duty, aluminum interlocking non-skid floor; Aluminum frame w/ 4" I-beams on 10" centers |
| Roof: | Single piece aluminum roof |
| Fenders: | Aluminum tear drop fenders |
| Rear Bumper: | 4" rear rubber bumper w/ skid pan |
| Running Boards: | N/A |
| Axles: | Two (2) rubber torsion axles with electric brakes on all wheels; 20'-24' = 7,000 lbs; 28' = 8,000 lbs |
| Tires: | Five 16" 8 hole steel wheels with 10 ply Goodyear tires (20'-24') or 14 ply Goodyear tires (28'); Includes spare |
| Landing Gear: | Adjustable 2 5/16" gooseneck coupler; Single leg landing gear w/ removable crank handle |
| Hitch Safety: | Breakaway switch w/ battery and slip hook safety chains |
| Exterior Lighting: | 4 rubber mounted LED stop, clearance and tail lights |
| Interior Lighting: | One LED dome light per compartment; One LED dome light in gooseneck nose |
| Other: | 1 5/8" x 3" side posts; 6" rear posts with heavy-duty rear gussets; Automotive style overhead wiring harness |
| Warranty: | 3/8 transferable warranty |
| Model | Coupler Type | Belly Length | Height | Width | GVWR | Weight | Axles |
| SR 8020 | Gooseneck | 20' | 6'8" or 7'2" | 8'0" | 14,000 LBS | 5,200 or 5,400 LBS | (2) 7,000 LBS |
| SR 8024 | Gooseneck | 24' | 6'8" or 7'2" | 8'0" | 14,000 LBS | 5,400 or 5,600 LBS | (2) 7,000 LBS |
| SR 8028 | Gooseneck | 28' | 6'8" or 7'2" | 8'0" | 16,000 LBS | 5,600 or 5,800 LBS | (2) 8,000 LBS |
SPECIFICATIONS, OPTIONS AND FEATURES ARE SUBJECT TO CHANGE WITHOUT NOTICE
Aluminum Wheels
2 Speed Manual Jack
2" Lower Air Gap
Easy Care Flooring
LED Load Light
Plexiglas
Rear Gate Slam Latch
Rubber Mats
Side Ramp
Vents in the Drop
